Traxxas Slash VXL HD 1/10 RTR 2WD Short Course Truck Fox 58376-74

Slash VXL 2WD 60 MPH Short Course Fun

Slash® VXL puts you in the driver’s seat for intense fender-to-fender short course racing action. Extreme Velineon® brushless power provides screaming 60+ mph speed with the advanced TQi™ radio system and Traxxas Stability Management® to keep everything under precise control. Slash VXL’s fully adjustable track-ready suspension now features Extreme Heavy Duty Upgrade parts to ensure Slash stays the undisputed leader in RC durability, performance, and fun.

Features

• Waterproof Velineon® VXL-3s Extreme Brushless Power System
• Factory-Installed Extreme HD Suspension and Driveline Components
• TQi™ 2.4 GHz High-Output Radio System with Traxxas Stability Management® (TSM)
• Pro-Series Magnum 272R™ High-Performance Transmission
• Pre-Painted Clipless Race Replica Body

VXL-3s Power System

Slash's Velineon VXL-3s™ brushless power system delivers the ultimate in efficiency, speed, and run-time with precise and responsive throttle control. Slash VXL transforms 11.1 volts of 3s LiPo power into 60+ mph speed and tire-scorching acceleration. This is brushless performance done the Traxxas way: brutally fast and easy to use.

Magnum 272R Transmission

The Magnum 272R transmission is built for the hard-hitting torque of Velineon brushless power. The 272R features a blue anodized aluminum motor plate, all-metal gears, and a sealed silicone-filled 4-gear differential. Slash VXL’s extreme HD driveshafts are also strengthened with large-diameter half shafts for increased power handling.

Extreme HD Suspension

Factory-installed Extreme Heavy Duty axle carriers, caster blocks, and steering blocks, are beefed-up with extra material to give Slash VXL ultimate strength and durability. With the addition of HD suspension arms made from Traxxas’ toughest composite material, this is the strongest suspension ever offered in a 2WD Slash.

Clipless Body Mounting

Slash VXL’s clipless body holds firm no matter how rough the racing gets. Heavy-duty latches grip the body tightly, but release in just seconds for fast battery swaps on the pit bench. This convenient hidden latching system replaces traditional body clips with large, reinforced panels to maintain body integrity and resist pull-through damage.

Includes

• Slash 2WD VXL RTR Truck
• Velineon 3500 Brushless Motor
• Velineon VXL-3s Electronic Speed Control
• TQ 2.4GHz Radio System
• Quick Start Guide
• Quality Tool Set

Requires

• 7.4V 2S LiPo or 7.2V 6-Cell NiMH or 8.4V 7-Cell NiMH Battery Pack
• Compatible Battery Charger
• (4) "AA" Batteries for Transmitter

• Model Name : Slash VXL 2WD
• Model Type : Short Course Truck
• Speed : 60+ mph
• Skill Level : 2
• Scale : 1/10
• Weight : 5.64 pounds (2.56 kg)
• Length : 22.8 inches (578 mm)
• Width : 11.65 inches (296 mm)
• Front Track : 11.65 inches (296 mm)
• RearTrack : 11.65 inches (296 mm)
• Height : 8.43 inches (214 mm)
• Wheelbase : 13.2 inches (335 mm)
• Center Ground Clearance : 3.5 inches (89 mm)
• Transmission : Magnum 272R
• Differential Type : Sealed, bevel gear
• Overall Drive Ratio : 2.72 (final drive: 12.2)
• Gear Pitch : 48 pitch
• Servo : 2075 digital high-torque waterproof
• Radio System : TQi™ 2.4 GHz 2-channel transmitter with TSM® receiver
• Battery Compartment Specs : 165 mm X 50 mm X 23 mm / 25 mm

MOTOR SPECS

• Motor Name : Velineon 3500
• Motor Type : Sensorless brushless
• Motor Weight : 9.24 ounces (262 g)
• Motor Length : 3.03 inches (77 mm) overall length, 2.2 inches (56 mm) can length
• Motor Diameter : 1.41 inches (36 mm)
• Motor Shaft Size : 3 mm
• Motor Connector Type : 3.5 mm bullet

ESC SPECS

• Name : VXL-3s electronic speed control
• Type : Brushless
• Case Size : 1.54 inches (39 mm) / 2.18 inches (55 mm) / 1.30 inches (33 mm)
• Weight : 3.17 ounces (90 g)
• Motor Connectors : 3.5 mm bullet
• Battery Connectors : Traxxas High-Current Connector
• ESC Power Wire : 12 gauge Maxx Cable
