Hobbywing HW38020349 Quicrun Combo WP 1080 G2 and 540-30T Brushed Motor

Product Code: HW38020349
Barcode: 6938994420112
$112.99
-
+

Stock levels are subject to continuous change and may vary from store to store. Store transfers and holds available on request by emailing support@metrohobbies.com.au

QuicRun 1080 G2 ESC

Features

  • Fully Water-proof and dust-proof, suitable for all-weather races.

  • Small in size, with a built-in capacitor module.

  • Four operating modes available (Real Car Operating / FWD with Brake / FWD and REV with Brake / FWD and REV)

  • In the first "real car mode" The direction of the motor is switchable in real time by using the idle channel on the remote control.

  • Real-Time Adjustment of Drag Braking Force.

  • 15 programmable parameter items

  • PWM Frequency: 1K/2K/4K/8K/16K Adjustable

  • Freewheeling (DEO) capability

  • Drag brake rate in 9 levels (adjustable)

  • Electronic switch

  • Aluminum case for great heat dissipation

  • Great current endurance capability.

  • Great built-in BEC output capacity switchable 6V/ 7.4/ 8.4V

  • Automatic throttle range calibration, easy to use.

  • Multiple protections

  • Over Voltage Protection

  • Low voltage cut-off protection for battery

  • Over-heating protection

  • Throttle signal loss protection, and much more

  • Risk-Free manufacturer's limited warranty available through Authorized Dealers in North America

WP-1080 G2 ESC VS WP-1080 (G1)

  • BEC output can go up to 8.4V

  • Real-Time Adjustment of Drag Braking Force.

  • Real Car Mode

  • New Aluminum case

Specifications

  • Waterproof Yes

  • Dual Mode No

  • Fwd Cont. / Peak Rev Cont. / Peak: 80A / 400A

  • Car Applicable: 1/10 Rock Crawler

  • Motor Limit: Brushed Motors 540/550 Series 2S LiPo or 5S NiMH 3S LiPo or 9S NiMH

  • Battery: 2-3S LiPo or 5-9S NiMH

  • BEC Output: 6V/7.4V/8.4V @ 4A (switch-mode)

  • PWM Frequency: Adjustable1K/2K/4K/8K/16K

  • Wires: 14AWG-200mm w/ XT60 Connector

  • Size/ Weight: 37.2(L)* 31.9(W)*18.4(H) (without fan)

  • External Program Port: Separate Port Available

  • Programming: LED Program card

  • Weight: 70.2g w/ wire and connectors

  • Cooling Fan

QuicRun Brushed motor (540 or 555 sizes)

QUICRUN Brushed 540 Specifications

  • Slot: 3

  • Turns: 30T

  • (RPM@7.4V): 14000

  • Input Voltage: 12.6V

  • Diameter/ Length(mm): φ=36mm(1.42in) L=53mm(2.09in)

  • Shaft Diameter/ Length (mm): φ=3.175mm(0.125in) L=16.5mm(0.65in)

  • Applications: 1/10 On-road / Buggy / Crawler & 2WD Truck

  • Weight: 168g
